Concrete Batching Plant

Concrete Batching Plant
Concrete Batching Plant
Product Code : NE-25 Cu M Per Hr
Brand Name : NE 25
Product Description

Owing to advanced manufacturing facilities, we are able to manufacture, supply and export precisely designed Concrete Batching Plant. All the plants offered by us are widely appreciated by our clients for their excellent attributes such as less maintenance, sturdy construction and anti-corrosive nature. These batching plants are used for carrying heavy machines from one place to another. Adding to this, Concrete Batching Plant is thoroughly checked on well-defined parameters before its final delivery so that only high quality product is delivered at clients' location within the committed time-frame.

(1) CONCRETE BATCHING PLANT, MODEL NE-25 OUTPUT CAPACITY 25 M3/HR.



Model NE-25 is a fully automatic, compact Concrete Batching Plant on single chassis with two nos. rear axle & one no. swiveling front axle. The towing arrangement in the plant facilitates it to be towed by tractor or equivalent power.

 The plant comprises of adequate capacity gravel & sand hoppers with conveyors, Pan type mixer unit, electronic load cells, water tank, cement silo with screw conveyor, Rubber belt type discharge conveyor, PLC based control panel and three axles fitted with pneumatic rubber tyres.

Construction Features:

  • Its compact design helps to move easily with tractor or similar power.
  • Its good modular construction is convenient for maintenance.
  • Its heavy duty robust chassis is fabricated by structural steel.
  • It is suitable for transportation of 40 feet trailer/container.
  • Easy to erect without using any foundation/civil work.
  • Minimal cycle time and consistent concrete quality.

 Component Features:

Two nos. twin hoppers i.e. total 4 nos. hoppers (2 x 2) for storage of gravels & sand. Two hopper storage capacities is 2.5 m3 and other two is 3 m3 and is fitted with pneumatic gate and rubber conveyor for feeding the ingredients into Pan Mixer unit. Bin vibratory motor is fitted on one hopper meant for sand.

Pan type Mixer unit of 0.75 m3 capacity constructed from heavy duty steel is having 10 mm thick wear resistant replaceable liner plate and spring loaded paddle mixer arms with replaceable blades. Hydraulically operated gate facilitates the discharge of concrete mix from bottom of Pan Mixer on to the discharge conveyor. The drive to the mixing arm is through planetary Gear Box coupled with motor. The Pan Mixer is placed on three nos. electronic load cells.

 TECHNICAL DATA:



WATER TANK

IN BUILT 900 LITRES

WATER PUMP

SUBMERSIBLE TYPE

ADDITIVE TANK

50 LTRS.

ADDITIVE PUMP

SELF PRIMING

CEMENT SILO

1.0 TONS

DISCHARGE HEIGHT

1 MTRS.

TYRE SIZE

750 x 16

TOTAL WEIGHT

11,000 KGS.

TOTAL CONNECTED H.P.

61.5 H.P.

POWER SUPPLY

415 V, 50 Hz, 3 PHASE, A.C.

MOTORS:

VIBRATORY MOTOR

PAN MIXER

WATER PUMP

ADDITIVE PUMP

SCREW CONVEYOR

CHARGING CONVEYOR

POWER PACK

AIR COMPRESSOR



1.0   H.P.

30.0 H.P.

3.0   H.P.

0.5   H.P.

7.5 H.P.

5.0   H.P.

3.0 H.P

5 H.P
